Gridman performed following:
- power plant modelling,
- reactive power and voltage capability study,
- reactive power compensation study,
- power quality study (harmonics, flicker and voltage unbalance).
Volvo Kosice, Slovakia
Protection & Coordination study
Project partner: Siemens, SAT automation
Gridman performed following:
- protection and coordination study for 110 kV main substation,
- protection and coordination for 22kV and 6kV internal electrical network.
Seabank, United Kingdom
Steam/Gas turbine modelling
Installed power: 910 MW
Project partner: Siemens Energy
Gridman performed following:
- development of the steam/gas turbine dynamic models in DigSilent PowerFactory/PSCAD,
- validation grid compliance studies against the grid (SMIB model),
- simulation tests on IEEE 9-bus system.
Gridman performed following:
- plant modelling in DigSilent PowerFactory,
- performing the grid code studies (Fault ride through, Active power step change, LFSM-O, Reactive Power capability),
- building and validating the plant EMT model in PSCAD.
Alveston, United Kingdom
Calculation of the DC Short-circuit currents in the internal parts of Battery Energy Storage System of the Onshore Wind Farm
Installed power: 22 MW
Project partners: ABB
Gridman performed following:
- power plant and BESS modelling,
- dc-short-circuit study,
- sizing of the BESS internal parts.
